Ricoh Imaging has announced an updated set of Pentax DA Limited primes, with improved lens coatings and circular aperture diaphragms. Based on the existing 15mm F4, 21mm F3.2, 35mm F2.8 Macro, 40mm F2.8 and 70mm F2.4 designs, the ‘HD’ versions gain Pentax’s multi-layer HD (High Definition) coating, promising reduced flare and ghosting, and include diaphragms that are completely rounded at large aperture settings to give attractive background blur. And they also announced the AF540FGZ II and AF360FGZ II Pentax-branded flash units. Both are updates to existing models, now boasting weather-sealed construction to match Pentax’s line of weatherized DSLRs. The new flash units also feature built-in LED lights, intended for video recording.
Buy Now:
Product | Buy Now |
---|---|
HD PENTAX DA 15mm F4 ED AL Limited | B&H/Adorama/ebay |
HD PENTAX DA 21mm F3.2 AL Limited | B&H/Adorama/ebay |
HD PENTAX DA 35mm f/2.8 Macro Limited | B&H/Adorama/ebay |
HD PENTAX DA 40mm F2.8 Limited | B&H/Adorama/ebay |
HD PENTAX DA 70mm F2.4 Limited | B&H/Adorama/ebay |
Pentax AF360FGZ II Flash | B&H/Adorama/ebay |
Pentax AF540FGZ II Flash | B&H/Adorama/ebay |
HD Pentax DA 15mm F4 ED AL Limited | HD Pentax DA 21mm F3.2 AL Limited | HD Pentax DA 35mm F2.8 Macro Limited | HD Pentax DA 40mm F2.8 Limited | HD Pentax DA 70mm F2.4 AL Limited | |
---|---|---|---|---|---|
Principal specifications | |||||
Lens type | Prime lens | ||||
Max Format size | APS-C / DX | ||||
Focal length | 15 mm | 21 mm | 35 mm | 40 mm | 70 mm |
Image stabilisation | No | ||||
Lens mount | Pentax KAF | ||||
Aperture | |||||
Maximum aperture | F4.0 | F3.2 | F2.8 | F2.4 | |
Minimum aperture | F22.0 | ||||
Aperture ring | No | ||||
Number of diaphragm blades | 9 | 7 | 9 | ||
Aperture notes | Rounded aperture diaphragm | ||||
Optics | |||||
Elements | 8 | 9 | 5 | 6 | |
Groups | 6 | 5 | 8 | 4 | 5 |
Special elements / coatings | 1 Hybrid aspherical element, 1 ED glass element, High-grade multi-layer HD (High Definition) Coating | High-grade multi-layer HD (High Definition) Coating | |||
Focus | |||||
Minimum focus | 0.18 m(7.09″) | 0.20 m(7.87″) | 0.14 m(5.47″) | 0.40 m(15.75″) | 0.70 m(27.56″) |
Maximum magnification | 0.15 x | 0.17 x | 1 x | 0.13 x | 0.12 x |
Autofocus | Yes | ||||
Motor type | Screw drive from camera | ||||
Full time manual | Yes | ||||
Focus method | Unit | Extending front | |||
Distance scale | Yes | ||||
DoF scale | Yes | No | Yes | ||
Physical | |||||
Weight | 189 g (0.42lb) | 134 g (0.30lb) | 214 g (0.47lb) | 80 g (0.18lb) | 147 g (0.32lb) |
Diameter | 63 mm (2.48″) | ||||
Length | 40 mm(1.56″) | 25 mm(0.98″) | 47 mm(1.83″) | 15 mm(0.59″) | 26 mm(1.02″) |
Colour | Black, Silver | ||||
Filter thread | 49 mm | ||||
Hood supplied | Yes | ||||
Hood product code | built-in hood | MH-RBB43 | built-in hood | MH-RE49 | MH-RF49 |
Tripod collar | No |
